TP50 Flex Probe Manipulator

TP50 Flexible Positioner

To support large number of oscilloscope and digital microscope users with a versatile holder without the need for xyz-stage, the compact TP50 is designed for ease of use with the highest quality; at the same time, it offers the most competitive price in the industry.

Specifications

  • Articulated arm: 4 links and 3 joints controlled by a single thumbscrew
  • Arm Length: 220 mm/8.7 in
  • Width: 76 mm/3.0 in
  • Height: 90 mm/3.5 in
  • Weight: 2,702 grams/5 lb 15.4 oz
  • Base: Rubber base with magnets at bottom
  • Small Adapter opening: 2-12 mm
  • Regular Adapter opening: 4-16 mm
  • Wide Adapter opening: 7-18 mm
  • Long Adapter: Holds probes up to 9.5 mm wide
  • Special Adapter: To hold Tek P7500 probe
Various adapters of TP50 Easy Positioner
Various adapters of TP50 Easy Positioner
TP50-LA12 with long adapter and Tek probe
TP50-LA12 with long adapter and Tek probe
TP50-TA10 with special adapter for Tek P7500 probe
TP50-TA10 with special adapter for
Tek P7500 probe

Highlights

  • Flexible long-reach arm controlled by a single thumbscrew
  • Probe tip contact pressure adjustment
  • Revolutionary adapter design can hold different probes with different sizes and shapes
  • Suitable for lengthy, unmanned testing and detection of hard-to-find glitches
  • Magnetic rubber base can be used on metal or non-metal bench
  • Availability: now
  • View TP50 Flex Positioner datasheet.



Multiple Adapters to Hold All Probes and Digital Microscopes

To cover wide range of shape and size of oscilloscope probes and how they are used in probing, PacketMicro offers several probe adapters to cover all of them.

  • The small adapter UA12 can hold smaller and lighter probes or digital microscopes up to 12 mm in diameter.
  • The regular adapter UA16 can hold probes or digital microscopes up to 16 mm.
  • The wide adapter UA18 can hold probes or digital microscopes up to 18 mm.
  • The pointed long adapter LA12 is for smaller probes while maintaining steady control.
  • The special adapter TA10 is to hold Tek P7500 probes.

Part Numbers

TP50-UA12: TP50 with small adapter
TP50-UA16: TP50 with regular adapter
TP50-UA18: TP50 with wide adapter
TP50-LA12: TP50 with long adapter
TP50-TA10: TP50 with special adapter to hold Tek P7500 probe

TP50 Demonstrations

TP50 Demonstration

 Eye diagram probing using TP50 to hold Tektronix Probe

TP50 Demonstration

Vertical probing with TP50 model
